Rotation Conventions

A side-by-side demonstration of the two rotation_mode values: ANTz's legacy Heading/Tilt/Roll (a Z-X-Z sequence) versus GlyphViz's per-axis Euler XYZ. Identical rotation inputs trace visibly different paths — a level circle under one convention, a wobbling one under the other.

Try it: download this example below (or the full examples set), then open Rotation_Convention_Example/Rotation_Convention_Example_gv_node.csv — or just drag its folder onto the GlyphViz window. Press Space to start the animation.

Download this example (4 KB)

What it is

Two pins stand side by side. They are given exactly the same numbers: a fixed tilt of 30° and a heading that sweeps from 0° to 360° over a four-second loop, driven by one shared channel. Yet they do not move the same way. The left pin's tip sweeps a perfectly level circle. The right pin's tip bobs up and down as it goes round.

The only difference between them is their rotation_mode, the setting that tells GlyphViz how to read the three rotation numbers.

	Left pin	Right pin
Label	Heading/Tilt/Roll (ANTz)	Euler XYZ
Convention	ANTz's legacy sequence	GlyphViz's own, and the default for new nodes
Path of the tip	a level circle at constant elevation	an elevation that wobbles through the sweep

Why the two differ

Heading/Tilt/Roll is the convention ANTz always used, borrowed from the way KML aims cameras and models. It is a Z-X-Z sequence: rotate_y is a heading about the vertical axis, rotate_x is a tilt, and rotate_z is a roll about the vertical axis again. Heading then tilt is the standard way of describing a direction on a sphere, azimuth and then elevation, the same longitude and latitude idea GlyphViz already uses to place children on a Sphere topology. Hold the tilt fixed and sweep the heading, and you get a lighthouse beam: a level circle.

Euler XYZ simply rotates about each named axis in turn: rotate_x about X, rotate_y about Y, rotate_z about Z. That is intuitive when you pose a glyph by hand, but the two angles no longer mean azimuth and elevation. Give it the same fixed rotate_x of 30 and a swept rotate_y, and the tip's elevation changes as the sweep proceeds.

One tempting explanation is wrong, and the scene is careful not to claim it: it is not that one mode can spin in place and the other cannot. rotate_z is the innermost rotation in both conventions, so animating only rotate_z looks identical in both. The real difference appears when rotate_x and rotate_y are both non-zero and jointly aim the object.

What to try

• Press Space and watch the two tips. Then orbit to look along the vertical axis: the left tip draws a circle, the right one an uneven loop.
• Open the Properties panel on each pin and find its Rotation Mode. Change the right pin to Heading/Tilt/Roll and the two become identical, because only the mode was ever different.
• Pause and set rotate_x to zero on both: with no tilt, the two conventions agree.

Why it matters when you write data

Files that predate this setting load as Heading/Tilt/Roll, so every older ANTz, GaiaViz and GlyphViz scene renders exactly as it always did. A node created in GlyphViz itself defaults to Euler XYZ. When you generate scenes, set rotation_mode explicitly on any node you rotate. It is the one column whose absence changes what the numbers mean.

The scene is two nodes and one channel, and the generator, generate_rotation_convention_example.py, is a good minimal model of a Channels animation: one mapping, one 120-frame track, and two nodes sharing it.
